What Is a Spacer Layer?
Learn how a precision-cut spacer layer creates a controlled capillary channel in BGM strips and other microfluidic diagnostic devices.
A spacer layer is a converted adhesive or film component that separates adjacent layers by a controlled distance. In diagnostic assemblies, its cut geometry often forms the sidewalls of a narrow fluid channel.
Creating a Functional Gap
The spacer prevents the cover film from contacting the sensor substrate across the entire area. The open region left by the die cut becomes a controlled pathway for the sample.
Material and Adhesive Considerations
PET-supported double-sided tapes are often selected for dimensional stability and clean processing. Thickness tolerance, adhesive coat weight, and compatibility with the surrounding stack require project-specific evaluation.
Converting Controls
Kiss cutting, waste removal, lamination, and registration must preserve narrow channel features. Inspection can verify critical dimensions, edge quality, and placement before downstream assembly.
Engineering Review
Key points to define for the project.
